M2630S-K2 CNC Pelletizer Hob Relief Grinding Machine

Guaranteed Safe Checkout

Product Introduction

Welcome to use the Model M2630S-K2 CNC Pelletizer Hob Relief Grinding Machine manufactured by Nanjing Weigao. This machine is designed for relieving the rake face of indexing tools such as straight-fluted hobs and form cutters, which are used in pelletizers.

This model features a self-developed 2-axis CNC system with a Chinese interface. The entire relieving process is controlled by servo motors. The machine adopts variable programming, allowing users to edit, store, and recall relieving programs for different tools. Operators only need to input corresponding variable data and working parameters to start a fully automatic grinding cycle. The operation is extremely simple, practical, and easy to learn, making it accessible for ordinary workers to operate proficiently.

Main Technical Specifications
Max. diameter of hob to be ground	260mm
Max. length of hob to be ground	300mm
Grinding head travel	400mm
Lead of hob flute	100mm – ∞
Max. helix angle of hob flute	±15°
Height from worktable to spindle center	160mm
Inclination angle of grinding wheel spindle centerline to worktable	15°
Vertical travel of grinding wheel	150mm
Grinding head motor power	1.5kW
Grinding head speed	3000rpm
Servo motors	X-axis: 1kW Y-axis: 2kW
Machine dimensions (L×W×H)	2100×1800×1900mm
Machine weight	2200kg
Grinding wheel specifications	Dish grinding wheel 200×20×32

Machine Accuracy
Positioning accuracy of X/Y axes	0.01 mm
Runout accuracy of centers	0.003~0.008 mm
Spindle runout accuracy of grinding head	0~5 μm
Indexing positioning accuracy	±12″
Indexing repeatability accuracy	±5″
